Task 1
In the near future after an apocalyptic nuclear disaster, a small group of renegades is in a bid to survive against the bad guys.
They have created a sensor-based alarm system which works as follows:
| sensor | condition | binary value |
|---|---|---|
| motion | nobody outside | 0 |
| somebody outside | 1 | |
| gas | oxygen level low | 0 |
| oxygen level fine | 1 | |
| pressure | escape vehicle not in correct place | 0 |
| escape vehicle in correct place | 1 |
A red light is automatically switched on in the secret bunker if:
there is somebody outside and the escape vehicle is in the correct place and the oxygen level is fine
Task 1.1
Design this circuit using circuitverse. Test it to see if it works.
Save a screenshot of your solution. Make sure it is labeled Task 1.
Task 2
The renegades have decided to change the logic of their security system to make it more robust.
A red light is automatically switched on in the secret bunker if:
there is somebody outside or the escape vehicle is not in the correct place
and
the oxygen level is fine
Task 2.1
Design this circuit using circuitverse. Test it to see if it works.
Save a screenshot of your solution. Make sure it is labeled Task 2.
Task 3
The logic is causing some problems and needs to be changed again:
A red light is automatically switched on in the secret bunker if:
there is somebody outside and the escape vehicle is not in the correct place
or
the oxygen level is not fine
Task 3.1
Design this circuit using circuitverse. Test it to see if it works.
Save a screenshot of your solution. Make sure it is labeled Task 2.
Task 3.2
Design the Truth Table of this circuit. Submit it along with the 3 screenshots you have already saved.
